1. Prepare and Calibrate High-Precision Equipment
Tools Required:
Digital Oscilloscope: Use a high-bandwidth (100+ MHz) oscilloscope with at least 1 GS/s sampling rate to accurately capture the fast transitions on CAN networks.
Differential Probes: Essential for high-accuracy readings on CAN_H and CAN_L without ground interference. Select probes rated for the expected voltage range and bandwidth of your network.
Termination Checkers: Check for 120-ohm termination resistors at both ends of the CAN bus. [...]
Read more >
Complete List of Chrysler, Jeep, Dodge Security Gateway Locations
Since 2018, Chrysler, Dodge, Jeep, and RAM vehicles have been equipped with a Security Gateway Module (SGM) to protect the vehicle's computer systems from unauthorized access. The SGM restricts certain diagnostic functions, necessitating specific procedures or tools to access the vehicle's systems. Below is a comprehensive list of SGM locations for various models:
RAM Vehicles:
2019-2021 RAM 1500 (New Body Style): Behind the OBDII port.
[...]
Read more >
Programming Nissan Juke 2020-2021 Keys with Autel IM608: Handling PIN Code Requests
When programming keys for a 2020-2021 Nissan Juke using the Autel IM608, you may encounter a prompt requesting a PIN code. This typically occurs during the key addition process, especially when the system generates an XML file containing specific data.
Solutions to Obtain the PIN Code:
Third-Party Services:
Acquire the PIN code through reputable third-party providers. Once obtained, input the code when prompted by [...]
Read more >
If your Xhorse Dolphin XP005L isn’t cutting Mercedes emergency keys correctly, it may be due to using the wrong blade type. To resolve this:
Identify the blade type for decoding (likely HU64-1 or HU64-2).
Confirm the blade type for cutting (probably HU64-3).
Follow these steps: decode, take a picture, swap blade type, write in, and cut.
Read more >
IMMO Data Extraction with VVDI2 and Pogo Pin
This guide shows how to use the VVDI2 tool with a pogo pin adapter to access immobilizer (IMMO) data for VAG vehicles. Position the pogo pin adapter on the correct GND point for accurate data retrieval.
Read more >
1. Prepare and Calibrate High-Precision Equipment
Tools Required:
Digital Oscilloscope: Use a high-bandwidth (100+ MHz) oscilloscope with at least 1 GS/s sampling rate to accurately capture the fast transitions on CAN networks.
Differential Probes: Essential for high-accuracy readings on CAN_H and CAN_L without ground interference. Select probes rated for the expected voltage range and bandwidth of your network.
Termination Checkers: Check for 120-ohm termination resistors at both ends of the CAN bus. [...]
Read more >
